Matched Pair JLM LA500A Opto Compressors (best for 500 series)

March 21, 2023

We have two units made-to-order JLM LA500A Opto compressors with new slow attack mod. Lead time: 1-2 weeks.

From the JLM Audio Website:

---

LA500A Opto compressor is our MAC comp in an API500 series format. It is a full ground-up redesign of the LA3A/LA2A type compressor with several extra features. We have kept all the audio oddities of the side chain to keep the compression signature and extreme compression depth but added extra ratio of 5:1 to 10:1 and side chain HPF switching FLAT, 100Hz & 200Hz so the low end can be fully compressed or removed from the side chain to let the low end breath and make it easy to balance the compressed sound.The audio path has been fully redesigned for better signal to noise and headroom while still having clarity and warmth so that it is at home tracking anything or paired on stereo buss duty. The LA500 is made so even at extreme settings is it hard to make the comp sound anything but fantastic.

Features:

• NEW Pull threshold pot for slow attack with orange led on front panel
• NEW Pull Makeup pot for stereo linking of compressors with blue led on front panel
• 3 x PCB’s have all parts values directly on overlay for fast building.
• Large 34mm white LED backlight GR/VU meter.
• Hard relay bypass when comp power off or switched to LA OFF.
• Meter switchable Gain Reduction / LA OFF (meter led off) / VU by toggle switch
• Electronic balanced input to handle extreme input levels without distortion.
• Large 32mm chicken head input level control for easy setting of compression level.
• Large 32mm Makeup level pot with 0 to 20dB of gain.
• Ratio switchable 3:1, 5:1 & 10:1 by toggle switch
• Sidechain High Pass Filter switchable FLAT, 100Hz, 200Hz.
• Huge output transformer (same size as Neve LO1166).
• Internal jumper for output ground lift.
• Double-sided Gold plated rear edge connector.
• 3mm black anodized laser cut, vertical linished with white lasered on text for long-lasting zero wear finish.
• Mix buss output on pin 11 for Radial Workhorse rack

---

These are made to order items. We do custom mods and can change out opamps, transformers and other parts. Please inquire via message first.

Price for two units ~1300EUR; matched pair. Available from our eBay Shop and by contacting us directly via E-Mail -> “contact form” on the end of this website, among most at this domin name (preferred as there’s no platform fees, special taxes etc. involved). Please make sure to give us up to three weeks to prepare the order, test- and measure the hardware in question and send it to your location insured!

► Permalink ◄

---

The ultimate 312: CAPI VP312DI with Litz-wire Transformers

March 18, 2023

We have another item for made-to-order sales: the CAPI VP312DI-VPR-Litz¹, two different DI configuration options. A very faithful replica of the API 312 mic pre with additional active or passive (you choose) Direct Inject (DI) HiZ Jack that has the same path as the mic input; so you get the option to use the Pad on the DI as well. The preamp comes with Greyhill Stepped Gain control Knob for easy recall, only using high grade audiophile components and a specially designed Litz wire 2503 Output Transformer².

Optional mods and custom OpAmps also possible on request.

Get in contact via [email protected] or .com to pre order your desired finished build for API 500 series VPR compliant.

DI/HiZ options:

• Passive DI
• Active FET DI

► Permalink ◄

---

Our first active opamp summing unit prototypes arrived!

March 18, 2023

We’ve received the first batch of prototypes of our active Summing mixer version: Tascam/DSUB25 to XLR/TRS combo Jack. “E-OpAmp-Z Summer” (PCB v1.1A). It uses a Texas Instruments NE5532ADR dual low noise opamp.

We also ordered two 3D printed PC-ABS cases for testing. They’re still in production, to be shipped soon for evaluation.

► Permalink ◄

---

API 312 Clones with mods: parallel compression, tape emulation, transformer saturation.

March 18, 2023

Today we received our order of colour modules for saturation, coloration and compression for mods to pre amps.

We’re now able to offer 1176 style 1:4 or brick wall compression ¹ via a blend knob in API 312 pre amp clones from link audio design ². these high quality pre amps also feature variable high & low pass filters, phantom power, Pad and a very useful addition of a fader for the channel independent of the gain knob among other neat updates to the original design well suited for modern recording studio setups and project studio work whether hybrid or purely analog. You can also choose custom OpAmps from original vintage API 2520s and high quality replicas like the CAPI CA-0252 ³ thereof from various vendors to the famous red dot opamp ⁴. A perfect proven combination for tracking/recording and mixing drums, acoustic instruments and vocals for rock, punk, metal, electronica,…..

In addition we can offer mods from tape saturation to tube coloration, Neve-style transformer sound for a big and warm low end added to the mid-forward punch that API pre amps are famous for and made history recording most of the classic rock records during the 70ies and from there on. Many more options and mods on request.

► Permalink ◄
